Flexible 24-Port Copper Cabling Platform
ZCPPU6A-1U24-KJ-B1 is a 19-inch 1U modular patch panel for structured copper cabling. Twenty-four individual openings accept compatible unshielded keystone jacks, allowing installers to build Cat5e, Cat6 or Cat6A termination fields around the actual project specification.
The snap-in structure supports efficient module installation and replacement, while front identification areas help technicians label ports and manage network moves, additions and changes.
Panel Design and Cable Management
The black metal panel uses SPCC construction with a silver rear support bar for stable rack installation.
Independent snap-in openings make it easy to populate only the ports required for the current deployment.
The integrated cable-management bar helps control cable routing and reduce strain behind the termination field.
Key Benefits
Use compatible Cat5e, Cat6 or Cat6A UTP modules to standardize one panel format across different projects.
Individual snap-in modules can be installed, inspected or replaced without changing the complete panel.
Front labeling positions support port numbering and structured network administration.
Populate ports as required and protect spare positions with compatible blank dustproof stoppers.
The support bar provides a defined pathway for grouping and securing horizontal cables.
The 19-inch 1U format integrates into common network cabinets and equipment racks.
Typical Applications
- Commercial building telecommunications rooms.
- Enterprise LAN and campus copper distribution.
- Data center cross-connect and equipment-rack organization.
- Security, wireless access point and IP device cabling.
- New installations and phased network expansion projects.
Selection Guide
Match the keystone jack and horizontal cable to the required Cat5e, Cat6 or Cat6A channel class.
Verify the module width, latch structure and termination depth against the panel opening before bulk ordering.
Specify whether the order requires an empty panel, separately packed modules or a project-specific loaded configuration.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product type | Empty unshielded modular patch panel |
| Model / SKU | ZCPPU6A-1U24-KJ-B1 |
| Rack format | 19-inch, 1U |
| Port capacity | 24 ports |
| Module compatibility | Compatible unshielded Cat5e, Cat6 and Cat6A keystone jacks |
| Panel material | SPCC |
| Front finish | Black |
| Rear support | Silver cable-management bar |
| Module mounting | Snap-in structure |
| Port identification | Front labels and inlaid identification marks |
| Unused ports | Compatible with optional blank dustproof stoppers |
| Standard contents | Patch panel and cable-management hardware; keystone jacks not included |
Packing Information
Standard packing is 1 piece per inner box and 10 pieces per carton. The listed inner-box size is 51 × 10 × 5.5 cm, and the listed carton size is 53 × 42.5 × 30.5 cm.
Confirm product labels, carton marks, module configuration, samples and required project documentation before production.
RFQ Checklist
Need a configuration check?
Send ZION your cable category, selected keystone jack, rack layout and project quantity for compatibility review.
FAQ
Are keystone jacks included with this patch panel?
No. The standard product is an empty patch panel, and keystone jack modules are not included in the standard packaging.
Which modules fit this panel?
The panel is intended for compatible unshielded Cat5e, Cat6 and Cat6A keystone jacks. Confirm the module dimensions and latch design before ordering.
Does the panel include cable management?
Yes. The design includes a rear support bar for organizing and securing horizontal cables.
Can unused ports be covered?
Yes. Compatible blank dustproof stoppers can be used in unused module positions.
What should be included in an RFQ?
Provide the model, required cable category, keystone jack type, loaded or empty configuration, quantity, labeling and packing requirements.
