FTTX ADSS Suspension Clamp J Hook Suspension Clamp for ADSS Fiber Optic Round Cable ZCTGC-02

FTTX ADSS Suspension Clamp
J Hook Suspension Clamp for ADSS Fiber Optic Round Cable

■ Specification:

P/N: ZCTGC-02

Product Material: Thermo-Plastic-Rubbermaterial+ Galvanized steel

(TP-RL+GS)

Product Size: 135*80*35mm

Bearing Tensile: 3.8 KN

Per Weight: 158 g

Applicable Wire Diameter: Φ8-12mm

Packing Specifications: Carton Size：40*30*30cm Weight：24.7KG

Single Box Quantity: 150pcs/Carton

Application: Fiber optical systems

Brand: HELLOSIGNAL® OR OEM

MOQ: 150pcs

■ Application:

• Widely applied in cable connecting fittings, to support wire, conductor, and cable in transmission line fittings.


• Local Area Networks.


• Suit for ADSS Fiber Optic Round Cable.


• Telecommunication Networks.


• Fiber to the Home (FTTH).


• Other applications in Fiber optical systems

■ Features:

• High tensile strength and stability.


• Special fixing method of soft rubber TPR.


• Self-adjustable wedge.


• Suitable for a full range of cable diameters from 3-20mm.


• Strong corrosion resistance, acid resistance, and alkalinity in the field.


• Simple, fast installation, not requiring other tools.


• Small diameter optical cable can clamp N roots.


• High quality with a Competitive price.


• Perfect environment stability.


• Effective cable clamping due to the conical wedging system.


• Easy to install, as long as only stainless steel strips or pigtail hooks or brackets can be installed to the rod or wall.


• Wide grip and mechanical resistance.

■ Description:

• This suspension clamp is composed of a TPR plastic insert and a galvanized steel shell. The unique soft-rubber wire clamping mechanism ensures stable and secure cable retention, specifically designed to suspend ADSS round optical fiber cables during transmission line construction. It clamps the optical cable without causing damage. A wide range of gripping capacities and mechanical resistance is achieved through diverse product specifications with interchangeable neoprene inserts.




• The metal hook of the suspension clamp allows for pole installation using stainless steel bands with pigtail hooks or brackets. The ADSS clamp hook can be manufactured from stainless steel materials upon request.

• The self-supporting optical cable suspension clamp serves as a fiber optic hardware device, primarily used for suspending ADSS cables or other self-supporting circular optical cables during optical network construction.

• Suspension Clamps HC are designed to suspend ADSS round optical fiber cables during transmission line construction. Each clamp consists of a plastic insert that securely grips the optical cable without damage. Mechanical resistance and various gripping capacities are achieved through a product range featuring multiple neoprene insert sizes.

• ADSS suspension clamps are utilized for direct suspension of round ADSS fiber-optic cables (Ø6-15mm diameter) on short spans (maximum 150m) at intermediate poles along straight routes. Select the appropriate model based on ADSS cable diameter.

• PS-ADSS clamps can be installed on hook brackets or used with stainless steel straps.

• A broad range of clamping capacities and mechanical resistance levels are achieved through an extensive product line with interchangeable rubber inserts.

• The cable clamp comprises a J-hook and a plastic insert that secures circular optical cables without damage.

• These clamps have passed rigorous testing, including:

• Tensile strength tests

• Operational temperature tests (-40°C to +60°C)

• Temperature cycling tests

• Aging tests

• Corrosion resistance tests
