NO.7100383 Кабель паракс РК 75-4-320

  • PK75

  • hellosignal

  • 7100383

Availability:

Specification

PK75-4-320 COAXIAL CABLE

Construction Parameters:
  Inner Conductor 1.02mm±0.02mm Copper
  Dielectric 4.60mm±0.10 Foamed PE
  Shield 1 AL/PET
  Shield 2 CuSn braid wire 81% coverage
  Outer sheath  6.80±0.20mm PVC
  *Notes AL/PET = Aluminium/Polyester
Electrical Characteristics:
  Inner Conductor Resistance 17.5Ω/KM
  Capacitance 54 ±3 pF/m
  Impedance 75 ± 3 Ω
  Return loss  between 5 and 1000MHz: > 22dB
  Velocity of Propagation  0.85
  Sparker Test (VAC) 4
Attenuation(20℃):
Frequency (MHZ)
        Max Attenuation (dB/100m)
10
2.10
50
4.40
220
9.20
470
14.30
862
19.90
1000
21.70
1350
25.60
1750
29.70
2150
33.20
2400
36.10
3000
40.70

Mechanical and Envrionmental Properties
  Cable bend radius 10 times the cable diameter
  Operating Temp Range  -20  to 60
  Cable diamensions 6.8±0.20mm PVC

Order Informations:
  Marking HELLOSIGNAL PK75-4-320 COAXIAL CABLE  ×××M
  Package 100M/Reel,300M/Wooden Spool (Per customers inquire)
  Delivery time Normally 25 days after received the deposit.
  Brand HELLOSIGNAL® OR OEM
