7/8" RF Coaxial Cable (No. 7101108)

■ Construction Parameters：

· Inner Conductor

· Material: Smooth Copper Tube

· Diameter: 9.00 ± 0.10 mm

· Insulation

· Material: Foamed PE

· Diameter: 22.60 ± 0.30 mm

· Outer Conductor

· Material: Annular Corrugated Copper Tube

· Diameter: 24.90 ± 0.30 mm

· Jacket

· Material: PE or LSZH

· Diameter: 27.50 ± 0.30 mm

■ Characteristics：

· Capacitance: 76 pF/m

· Impedance: 50 ± 2 Ω

· Velocity of Propagation: 0.88

· Peak Power Rating: 90 kW

· Maximum Operating Frequency: 5.2 GHz

· Insulation Resistance: >10000 MΩ·km

· DC Breakdown Voltage: 10000 V

· Jacket Spark Test Voltage: 8000 Vrms

· Inner Conductor DC Resistance: ≤ 2.65 Ω/km

· Outer Conductor DC Resistance: ≥ 2.30 Ω/km

· Shielding Attenuation: ≥ 120 dB

· VSWR (Voltage Standing Wave Ratio)

· 690 MHz - 960 MHz: ≤ 1.15

· 1700 MHz - 2700 MHz: ≤ 1.20

· 3300 MHz - 4200 MHz: ≤ 1.20

· PIM (Passive Intermodulation)

· Intermodulation (3rd order, 2 * 20 W): ≤ -160 dBc

■ Mechanical Properties：

· Bending Radius (Single Bend): 130 mm

· Bending Radius (Repeated Bend): 250 mm

· Bending Moment: 16 Nm

· Flat Plate Crush Strength: 8 N/mm

· Tensile Strength: 1400 N

■ Environmental Specifications：

· Installation Temperature

· PE Jacket: -40°C to +60°C

· LSZH Jacket: -20°C to +60°C

· Operating Temperature

· PE Jacket: -55°C to +85°C

· LSZH Jacket: -30°C to +80°C

· Storage Temperature

· PE Jacket: -70°C to +85°C

· LSZH Jacket: -30°C to +80°C

■ Attenuation (20℃)：

· Frequency (MHz) and Attenuation (dB/100m)

· 200 MHz: 1.69 dB/100m

· 450 MHz: 2.65 dB/100m

· 800 MHz: 3.64 dB/100m

· 900 MHz: 3.86 dB/100m

· 1800 MHz: 5.76 dB/100m

· 2000 MHz: 6.12 dB/100m

· 2200 MHz: 6.46 dB/100m

· 2500 MHz: 6.97 dB/100m

· 2700 MHz: 7.28 dB/100m

· 3000 MHz: 7.76 dB/100m

· 3500 MHz: 8.35 dB/100m

· 4000 MHz: 9.09 dB/100m

· 5000 MHz: 10.46 dB/100m

· Average Power (kW)

· 200 MHz: 6.27 kW

· 450 MHz: 3.73 kW

· 800 MHz: 2.49 kW

· 900 MHz: 2.34 kW

· 1800 MHz: 1.73 kW

· 2000 MHz: 1.63 kW

· 2200 MHz: 1.40 kW

· 2500 MHz: 1.33 kW

· 2700 MHz: 1.25 kW

· 3000 MHz: 1.16 kW

· 3500 MHz: 1.05 kW

· 4000 MHz: 0.99 kW

· 5000 MHz: 0.94 kW

· Note: Maximum attenuation value shall be 105% (some will be 110%) of the above nominal attenuation value.

■ Standards：

· Fire Resistant: IEC 60754-1, IEC 60754-2, IEC 60332-1, IEC 60332-2, IEC 61034-1, IEC 60332-3-24

· RoHS: Compliant with RoHS 2011/65/EU

· REACH: Compliant

· CPR (Construction Products Regulation)

· CPR EURO Level: Fca, Eca, B2ca-s1b,d0,a1

■ SKU and Marking：

· SKU Examples

· 7101108-PEBK-500M: 7/8" RF Coax Cable PE Black Jacket (CPR Fca) 500M

· 7101108-OEBK-500M: 7/8" RF Coax Cable LSZH Black Jacket (CPR Eca) 500M

· 7101108-OB2BK-500M: 7/8" RF Coax Cable LSZH Black Jacket (CPR B2ca-s1b,d0,a1) 500M

· 7101108-××××-×××M: ××××-×××M will be named by Test inquired and Packing Length

· Marking on Cable Jacket: ZION 7/8" RF COAXIAL CABLE 7101108-××××-×××M

■ Packing：

· Packing Length: 500M (Standard)
