NO.7102063 3C-2V+2c x0.50 Common

3C-2V+2x0.50,Common

NO.7102063

Construction Parameters:

Inner Conductor

0.50mm Copper

Dielectric

3.2mm Foamed Polyethylene

Shield 1

Al Foil

Shield 2

0.12mmCCA-Braid(48%)

Jacket

5.0mm PVC/PE/LSZH

Power Wire Conductor

2x(11*0.25mmCCA )

Power wire Diameter

1.6mmPVC (Red,Black)

Jacket

6.6×8.2mm PVC/PE/LSZH

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor                         Resistance

The Max. at 20℃ shall be <87.6Ω/km

Capacitance

69±4 pF/m

Impedance

75 ± 3 Ω

Return loss

between 5 and 1000MHz: > 20dB

Velocity of Propagation

Sparker Test (VAC)

1

Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20 ℃ to 60℃

Cable diamensions

6.6×8.2mm

Cross Section

Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100ft)

Max Attenuation (dB/100m)

10

4.80

30

8.30

72

12.90

88

14.20

90

14.40

135

17.60

180

20.40

220

22.50

270

24.90

440

31.80

750

41.60

770

42.10

Order Informations

Marking

HELLOSIGNAL 3C-2V+2x0.50,Common
CCTV COAXIAL CABLE 7102063 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL^® OR OEM
