NO.7110326 16AWG 2/C STR Shielded FPLR-CL2R Fire Alarm Cables

16AWG 2/C STR Shielded  FPLR-CL2R

Fire Alarm Cables

NO.7110326

■ Cable Construction:

Conductor:

16AWG Stranded Bare Copper

16 AWG : 7/24, 65/34, 26/30, 19/29, 105/36

Nom.Dia:0.051''(1.29mm)

Dielectric:

Type: PVC

Dia.over Dielectric: 0.074±0.004''nom.(1.88±0.10mm)

Drain Wire: 0.51mm Solid Tinned-Copper

Shield :0.001"(0.025mm) thick Aluminum/Mylar

Color Code:

Blk

Red

Jacket:

Type: PVC

Color: Red

Dia.over Jacket: 0.182"±0.006''(4.62±0.15mm)

Print Legend:

HELLOSIGNAL NO.7110326 16AWG 2C 75C E××××××(UL) STR Shielded  FPLR-CL2R

SUN RES(ROHS) ××××M/FT DEVICE/ZONE

A B C D E F 1 2 3 4 5 6 7 8 9

■ Electrical Properties:

Temperature Rating: -20℃ ~ +75℃

Operating Voltage: 300 Volts max

Capacitance: 46 pf/ft nom

Impedance: 34 Ohms nom

DC Resistance: 4.1 Ohms/M' at 20℃

■ Cross Section:

■ Order Information:

Package: Inquired Length on Reel,Pull Box,Plastic Spool,Wooden Spool,Pallet

Delivery Time: Normally 25 days after receiving the deposit.

Brand: HELLOSIGNAL®OEM
