NO.7110331 18AWG 2/C STR Mid.Capaitance Shielded FPLR-CL2R Fire Alarm Cables

18AWG 2/C STR Mid.Capacitance Shielded FPLR-CL2R

Fire Alarm Cables

NO.7110234

■ Cable Construction

Conductor:

Material: 18 AWG Stranded Bare Copper

Stranding Options:7/26,16/30,19/30,41/34,65/36

Nominal Diameter: 0.04" (1.02 mm)

Dielectric:

Type: PVC

Diameter over Dielectric: 0.0637" ± 0.004" nominal (1.62 ± 0.10 mm)

Drain Wire: 0.51 mm Solid Tinned-Copper

Shield: 0.001" (0.025 mm) thick Aluminum/Mylar

Color Code: Black (Blk) Red

Jacket:

Type: PVC

Color: Red

Diameter over Jacket: 0.164" ± 0.006" (4.16 ± 0.15 mm)

Print Legend:

HELLOSIGNAL NO.7110034 18AWG 2C 75C E××××××(UL)

STR Mid.Capaitance Shielded FPLR-CL2R

SUN RES(ROHS) ××××M/FT DEVICE/ZONE

A B C D E F 1 2 3 4 5 6 7 8 9

■ Electrical Properties:

Temperature Rating: -20°C to +75°C

Operating Voltage: 300 Volts max

Capacitance: 17 pF/ft nominal

Impedance: 100 Ohms nominal

DC Resistance: 6.25 Ohms/M' at 20°C

■ Cross Section:

■ Order Information:

Package: Inquired Length on Reel, Pull Box, Plastic Spool,wooden Spool,pallet...

Delivery Time: Normally 25 days after receiving the deposit.

Brand: HELLOSIGNAL® or OEM
