NO.7110407 PH30 3×1.5mm² Fire Alarm Cables

PH30 3×1.5mm²

Fire Alarm Cables

NO.7110407

■ Cable Construction:

Conductor: 1.5 mm² Plain annealed copper wire, class 1, 2, or 5 according to EN60228.

Insulation

Material: Fire-resistant silicone rubber (BS 6387 CWZ, EN 50200 PH30, IEC 60331)

Diameter over Dielectric: 3 × (0.0102" (2.6 mm))

Insulation Color: Brown (Brn) / Black (Blk) / Gray (Gry)

Separator: PET Foil

Drain Wire: 0.80 mm Solid tinned copper

Shield: Aluminum PET (100% coverage, 20% overlapping)

Jacket:

Material: FR-LSZH (Red or White)

Diameter over Jacket: 0.291" ± 0.006" (7.40 ± 0.15 mm)

Standards: HFFR EN 50290-2, BS 7655 LTS1/LTS3

Print Legend:

HELLOSIGNAL Fire Alarm Cable PH30 1.5mm² 3 Cores Class N

BC BS 50200:2006 NO.7110407 ××××M/FT

■ Electrical Properties (at20℃):

Minimum Bend Radius: 8 × Diameter

Minimum Insulation Resistance: 200 MΩ/km

Maximum Working Temperature: -30°C to +90°C

Test Voltage: 2000 V

Maximum Operating Voltage: 300 V / 600 V

Maximum Resistance of Conductor:

Class 1, 2: 12 Ω/km

Class 5: 12.9 Ω/km



■ Cross Section:

■ Test Standards

Flame Tests

• BS 4066 Part 1 & 3

• IEC 60331

• BS 6387 CWZ

• IEC 60332-3-24

• EN 50200 PH30

• HD 606

• IEC/EN 60332-1



Insulation Integrity

• BS 7622



Smoke Density

• IEC/EN 61034



Corrosive Gas Measurement

• IEC 60754-2

• BS EN 50267-2-2

• EN 50266-2-4

■ Order Information:

Package: 100M/Wooden Spool,200M/Wooden Spool,500M/Wooden Spool

Delivery Time: Normally 25 days after receiving the deposit.

Brand: HELLOSIGNAL®OEM (Original Equipment Manufacturer)
