NO.7112110 U/UTP CAT 5E BC PVC for 4K IP Camera

  • U/UTP CAT5e

  • hellosignal

  • 7112110

  • CAT5E

  • 100 ohm

  • UL, ETL, CE,CPR, RoHS

  • 100m,305m,500m,500ft,1000ft

  • pull box, wooden spool, carton, pallet

  • 30KM

  • Normally 25 working days

  • NINGBO, SHANGHAI

  • T/T, L/C at sight, D/P at sight

Availability:

Specification

4K Network Camera CAT5E Ethernet Network Cable
NO.7112110









Construction

Conductor:

0.45mm Solid Bare Copper

Pairs:

4 Pairs

Insulation:

0.82 mm HDPE

Insulation Colors:

Blue-White/Blue,Orange-White/Orange

Green-White/Green,Brown-White/Brown

Rip Cord:

Cotton

Out Jacket:

4.7±0.2 mm  PVC









Electrical Characteristics

Impedance

1 - 100MHz 100±15 Ohms

Insulation Resistance

>5000MΩ*KM

Dielectric strength

DC  2500V  2S

Max.Conductor DC
Resistance 20℃

12 Ohms/100m

Res. unbalance (%)

Max. 2.5

Pair to Ground
Capacitance Unbalance

330 pF/100m

Transfer Impendance

Max 10 mOhms/m  @100Mhz

Installation temp.

 -30 - 50℃

Operation temp.

 -20 - 75℃









Cross Section




 Application

•  Meets or exceeds requirements of ANSI/TIA-568-C.2 Category 5e and

   ISO 11801 2nd Edition Class D channel standards.

•  Meets or exceeds requirements of ANSI/TIA-568-C.2 and IEC 61156-5

   Category 5e component standards.

•  Third party tested to Category 5e channel compliance.

•  Meets requirements of IEEE 802.3af and IEEE 802.3at for PoE applications.

•  Descending length cable markings enable easy identification of remaining cable

   which reduces installation time and cable scrap.

•  Color Availability: Additional cable colors available.









Order Informations

Marking

HELLOSIGNAL NO.7112110 U/UTP CAT 5E 4PR 24AWG PVC
XXX (or Per customer's request)

Inner Package

305m/Spool,305m/Reel (or Per customer's request)

Outer Package

Color Box, Pallet (or Per customer's request)

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL®   OR OEM




Packing

PACKING
062-508_S_RD_B            0-CAT5E-BL            0-CAT5E-BK
cat 5e pull box's packing1             cat 5e pull box's packing2
cat 5e 's packing3             cat 5e 's packing4

network cable's packing



packing6

www.zion-communication.com



packing7
