PH30 U/UTP CAT 5e
hellosignal
7112181
CAT 5E
100 ohm
UL, ETL, CE,CPR, RoHS
100m,305m,500m,500ft,1000ft
pull box, wooden spool, carton, pallet
30KM
Normally 25 working days
NINGBO, SHANGHAI
T/T, L/C at sight, D/P at sight
PH30 U/UTP CAT 5e -Global Market （PH30U5E) | ||||||||
Construction | ||||||||
Conductor: | 0.54mm Solid Bare Copper | |||||||
Pairs: | 4 Pairs | |||||||
Insulation 1: | 0.95±0.05 mm HDPE | |||||||
Insulation 2: | 1.20±0.05 mm Silicone | |||||||
Insulation Colors: | Blue-White/Blue,Orange-White/Orange | |||||||
Green-White/Green,Brown-White/Brown | ||||||||
Rip Cord: | Cotton or Fibre | |||||||
Out Jacket: | 6.5±0.2 mm LSZH | |||||||
Cross Section | ||||||||
| ||||||||
COMPLIANCE （Reference Standard and Certificates) | ||||||||
· ISO/IEC 11801-1 Ed.1.0 | ||||||||
· ANSI/TIA-568-C.2 、 ANSI/TIA-568.2-D | ||||||||
· UL444、UL1581、UL1666、IEC60332-1、EN50399 | ||||||||
Application Support | ||||||||
· 1000BASE-T 、 100BASE-T 、 10BASE-T | ||||||||
· 1Volp、ISDN、 Token、 100MTPPDM、 Analogand Datavideo、 POE Type1,2,3,4 | ||||||||
Electrical Characteristics | ||||||||
DC Resistance | ＜9.38 Ohms/100m @20℃ | |||||||
DC Resistance unbalance | 5% @ 20℃ | |||||||
Mutual Capacitance | 5.6 nF/100m | |||||||
Characteristic Impedance | 1 - 100 MHz : 100±15 Ohms | |||||||
100 - 350 MHz : 100±22 Ohms | ||||||||
Max Frequency | 100MHz | |||||||
Capacitance Unbalance | 330 pF/100m | |||||||
NVP(传输速率） | 67% | |||||||
Delay Skew | ≤ 45ns/100m | |||||||
PHYSICAL PROPERTIES | ||||||||
Pulling Tension(Max) | ≥13.5Mpa | |||||||
Bend Radius(Min) | 8×OD of Jacket | |||||||
Operating Temperature | -20 to 60 ℃ （-4 to 140℉） | |||||||
Performance Characteristics | ||||||||
Frequency | RL (Min.) | Insertion Loss(Max.) | Propagation Delay (Max.) | Delay Skew(Max.) | NEXT (Min.) | PSNEXT (Min.) | ELNEXT (Min.) | PSELNEXT (Min.) |
MHz | dB | dB/100m | ns/100m | ns/100m | dB | dB | dB/100m | dB/100m |
1 | 20.0 | 2.2 | 570.0 | 45.0 | 65.0 | 62.0 | 61.0 | 61.0 |
4 | 23.0 | 4.2 | 552.0 | 45.0 | 56.0 | 53.0 | 48.0 | 48.0 |
10 | 25.0 | 6.5 | 545.0 | 45.0 | 50.0 | 47.0 | 41.0 | 41.0 |
16 | 25.0 | 8.4 | 543.0 | 45.0 | 47.0 | 44.0 | 36.0 | 36.0 |
20 | 25.0 | 9.3 | 542.0 | 45.0 | 45.0 | 42.0 | 34.0 | 34.0 |
31.25 | 23.6 | 11.6 | 540.0 | 45.0 | 42.0 | 39.0 | 31.0 | 31.0 |
62.5 | 21.5 | 17.0 | 539.0 | 45.0 | 38.0 | 35.0 | 25.0 | 25.0 |
100 | 20.1 | 22.0 | 538.0 | 45.0 | 35.0 | 32.0 | 21.0 | 21.0 |
※Note: The above transmission performance tor the 100M, 20±2℃ under the conditions tested. | ||||||||
Test Standards | ||||||||
Fire resistant | EN50200 (30min) | IEC 60331-1/2 (30min) | |||||||
Acid Gas emission | EN 60754-1 | IEC 60754-1 | |||||||
Smoke Density | EN 61034-2 | IEC 61034-2 | |||||||
Order Informations | ||||||||
Marking | HELLOSIGNAL PH30 U/UTP CAT5E 4PR LSZH ...500M | |||||||
Inner Package | 500m/Wooden Spool | |||||||
Outer Package | Carton (38×38×30CM) | |||||||
Delivery time | Normally 25 days after received the deposit. | |||||||
Brand | HELLOSIGNAL® OR OEM | |||||||
