NO.7101031 RGC 213 CCA Cable

Construction Parameters:

Inner Conductor

2.55±0.03mm Copper-clad aluminum wire

Dielectric

7.25±0.15mm Foamed PE

Shield

Bonded Aluminum polyester tape

Outer Conductor

8.14mm Tinned Copper Braid (78%)

Jacket

10.35±0.2mm PE Black

More choice of Jacket

PE

Electrical Characteristics:

Capacitance

78.2 pF/m

Impedance

50±2 Ω

Velocity of Propagation

80%

RF

0.5 kV r.m.s

Max.Operating Frequency

3 GHz

Insulation Resistantce

>5000 M Ω.km

Shielding Effectiveness

> 90 dB

Inner Conductor DC Resistance

5.3 Ω/km

Outer Conductor DC Resistance

8.0 Ω/km

VSWR ≤ (Return loss≥dB)

30MHz-3000MHz

1.20 (20)

Mechanical and Envrionmental Properties:

Cable Bend Radius

Installation: 50mm

Repeated: 205mm

Compressive flat force

Maximum tension

88 kg

Recommended
Temperature

Storage:

- 70 ℃ to +85℃

Installation:

- 40 ℃ to +85℃

Operating:

- 40 ℃ to +85℃

Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100m)

0.5

0.66

1

0.88

5

1.32

10

1.76

20

2.31

30

2.64

50

3.30

88

4.29

100

4.62

108

4.73

150

5.72

174

5.88

200

6.41

300

7.98

400

9.35

450

9.98

500

10.50

512

10.71

600

11.76

700

12.81

800

13.86

824

14.07

894

14.60

900

14.70

925

15.02

960

15.33

1000

15.65

1250

17.75

1500

19.74

1700

21.21

1800

21.95

2000

23.42

2400

26.46

3000

28.35

Order Informations:

Marking

ZION 7101031 RGC 213 CCA 50 Ohm COAXIAL CABLE ×××M

Package

500M/Wooden Drum

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
