NO.7101131 1/2" H Radiating Leaky Cable

CABLE TYPE: RFXT 1/2”-50H(BHF)；HLRCAY(Z)-50-12H

Construction

Inner Conductor

copper tube

Ø 4.8 mm

Dielectric

Cellular polyethylene

Ø 12.2 mm

Outer Conductor

Copper foil

Ø 13.2 mm

Jacket

Black PE or Black LSZH

Ø 15.8 mm

Marking

Brand, cable type, cable ID, meter mark

Electrical Characteristics at +20℃

Characteristic impedance

50 ± 2 Ω

Velocity

0.88

Capacitance

76 pF/m

Insulation Resistantce

>5000 MΩ.km

Insulation Voltage

6000 V

Jacket Spark Test Voltage

8000 V

VSWR

Frequency (MHz)

 VSWR (Max)

790~960

1.30

1700~1900

1900~2025

1.40

2100~2200

2300~2500

2500~2700

MECHANICAL CHARACTERISTICS

Weigh

210kg/km

Maximum pulling force

1000N

Minimum bending radius

Single bending

125 mm

Repeated bending

350 mm

Operating temperature range

-40~ +80℃

Min. installation temperature

-20℃  (PE);
-5℃   (LSZH)

Attenuation and Coupling Loss

Frequency
(MHZ)

Attenuation
dB/100m
@20℃

Coupling Loss
(50%/95%)
 dB

800

7.3

79/84

900

7.9

76/82

1800

14.3

67/70

1900

15.0

67/71

2000

15.7

68/72

2200

16.7

67/71

2400

17.6

67/72

2600

18.6

65/69

2700

18.9

66/70

Note: Attenuation tolerance 5%; Coupling Loss tolerance ±5dB

Order Informations:

Marking

HELLOSIGNAL 1/2” Radiating Leaky Cable（H Band） ××× M

Package

Inquired Length on Wooden Drum and Pallet.

Brand

HELLOSIGNAL® OR OEM
