1 1/4”Radiating Leaky Cable（M Band）NO.7101133

Cable Type: RFXT 1 1/4”-50M(BHF); HLRCTCY(Z)-50-32M

■ Construction:

Inner Conductor: Copper tube, Ø 13.1 mm

Dielectric: Cellular polyethylene, Ø 33.0 mm

Outer Conductor: Copper foil, Ø 34.0 mm (Max)

Jacket: Black PE or Black LSZH, Ø 37.5 mm (Max)

Marking: Brand, cable type, cable ID, meter mark

■ Electrical Characteristics at +20℃:

Characteristic Impedance: 50 ± 2 Ω

Velocity: 0.88

Capacitance: 76 pF/m

Insulation Resistance: > 5000 MΩ·km

Insulation Voltage: 15000 V

Jacket Spark Test Voltage: 10000 V

■ VSWR:

100~200 MHz: 1.3

320~480 MHz: 1.3

680~700 MHz: 1.3

790~960 MHz: 1.3

■ Mechanical Characteristics:

Weight: 780 kg/km

Maximum Pulling Force: 2000 N

Minimum Bending Radius:

Single Bending: 400 mm

Repeated Bending: 500 mm

Operating Temperature Range: -40°C to +80°C

Minimum Installation Temperature: -20°C (PE); -5°C (LSZH)

■ Attenuation and Coupling Loss:

Frequency (MHz): 75

• Attenuation (dB/100m): 0.7

• Coupling Loss (50%/95%) (dB): 61/69

Frequency (MHz): 150

• Attenuation (dB/100m): 1.1

• Coupling Loss (50%/95%) (dB): 70/79

Frequency (MHz): 350

• Attenuation (dB/100m): 1.8

• Coupling Loss (50%/95%) (dB): 74/82

Frequency (MHz): 450

• Attenuation (dB/100m): 2.1

• Coupling Loss (50%/95%) (dB): 71/78

Frequency (MHz): 700

• Attenuation (dB/100m): 2.7

• Coupling Loss (50%/95%) (dB): 72/80

Frequency (MHz): 800

• Attenuation (dB/100m): 3.0

• Coupling Loss (50%/95%) (dB): 64/68

Frequency (MHz): 900

• Attenuation (dB/100m): 3.3

• Coupling Loss (50%/95%) (dB): 64/69

Frequency (MHz): 960

• Attenuation (dB/100m): 3.4

• Coupling Loss (50%/95%) (dB): 72/80

Note: Coupling Loss tolerance ±5 dB

■ Order Information:

Marking: HELLOSIGNAL 1 1/4” Radiating Leaky Cable (M Band) ××× M

Package: Inquired length on Wooden Drum and Pallet.

Brand: HELLOSIGNAL® or OEM
