JIS C 50
hellosignal
7101417
Coaxial Cable
50 ohm
UL, ETL, CE,CPR, RoHS
100m, 305m,500m,1000m,500ft,1000ft
roll, wooden spool, carton, pallet
10KM
Normally 25 working days
NINGBO, SHANGHAI
T/T, L/C at sight, D/P at sight
10D-FB CCA TC PE (SKU: 7101417) | ||||||||
Construction Parameters: | ||||||||
Inner Conductor | 3.50±0.03mm Copper Clad Aluminum | |||||||
Dielectric | 10.0±0.15mm Foamed PE | |||||||
Shield | Bonded AL/PET/AL Foil | |||||||
Outer Conductor | 24×8×0.16mm Tinned Copper Braid (86%) | |||||||
Jacket | 13.0±0.20mm PE Black | |||||||
| ||||||||
Capacitance | 84 pF/m | |||||||
Impedance | 50 Ω | |||||||
Velocity of Propagation | 82% | |||||||
DC Test Voltage | 3000 V | |||||||
Jacket/Sheath Spark | 8000V (V.RMS) | |||||||
Return Loss | ≥ 20.8 dB | |||||||
Mechanical and Environmental Properties: | ||||||||
Cable Bend Radius | 65mm | |||||||
Tensile Strength | 125 KG | |||||||
Storage Temp. Range | -70 ℃ to +85℃ | |||||||
Operating Temp. Range | -40 ℃ to +85℃ | |||||||
Cable Diamensions | 13.00mm | |||||||
Attenuation(20℃): | ||||||||
Frequency (MHZ) | Max Attenuation (dB/100m) | |||||||
150 | 4.10 | |||||||
280 | 5.70 | |||||||
350 | 6.40 | |||||||
400 | 6.90 | |||||||
800 | 10.30 | |||||||
900 | 11.00 | |||||||
1200 | 13.10 | |||||||
1500 | 15.00 | |||||||
1900 | 17.40 | |||||||
2000 | 18.00 | |||||||
2400 | 20.50 | |||||||
3000 | ||||||||
Order Informations: | ||||||||
Marking | ZION 7101417 10D-FB 50 Ohm COAXIAL CABLE ×××M | |||||||
Package | Inquired Length on Roll, Wooden Spool, Pallet … | |||||||
Delivery time | Normally 25 days after received the deposit. | |||||||
Brand | HELLOSIGNAL® OR OEM | |||||||
