SA Wall Box | |||||||||
Technical Data | |||||||||
Materials: | |||||||||
· SPCC Cold Rolled Steel; | |||||||||
· Thickness: 19" rails:1.2/1.5mm | |||||||||
· others: 1.2mm. | |||||||||
Colour: | |||||||||
· ZCSA.■■■■0■■: RAL7035 | |||||||||
· ZCSA.■■■■1■■: RAL9004 | |||||||||
Loading Capacity: | |||||||||
· Static loading: 60KG. | |||||||||
COMPLIANCE (Reference Standard) | |||||||||
· Comply with ANSI/EIA RS-310-D | |||||||||
· IEC60297-2 | |||||||||
· DIN41494;PART1; DIN41494;PART7. | |||||||||
Feature | |||||||||
· Welded frame, reliable structure; · Standing or wall mounting installation; · Adjustable feet and heavy duty castors are optional; · Easy mounting installation ( patent) ; · 19“ standard installation; · Removable side panels, side locks optional · Cable entry on both of top cover and bottom panel; · 120mm fan available; · Turning angle of front door is over 1 80 degrees | |||||||||
Definition Of Cord | |||||||||
Main Part | |||||||||
S/N | Specification | Qty | Material | Surface Finish | Remark | ||||
1 | Front door | 1 | 5MM toughed glass | Powder coated | ····· | ||||
2 | Side panel | 2 | SPCC t1.0 | Powder coated | ····· | ||||
3 | Frame | 1 | SPCC t1.2 | Powder coated | ····· | ||||
4 | Mounting profile | 1 | SPCC t1.2 | Powder coated | ····· | ||||
5 | Back panel | 1 | SPCC t1.0 | Powder coated | ····· | ||||
6 | 19"rails | 4 | SPCC t1.2/1.5 | Powder coated | <15U Thinkness : 1.2mm | ||||
A | M6 screw&nuts | 10 | Steel | Color zinc | 20pcs for over 12U | ||||
B | Trox tooling | 1 | Steel | Black | ····· | ||||
Order Information: | |||||||||
Part Number. | RU | Width | Depth(D) | Height(H) | Packing dimension(mm) | ||||
ZCSA.6406.SASS | 6 | 600 | 450 | 370 | 620*470*390 | ||||
ZCSA.6606.SASS | 600 | 620*620*390 | |||||||
ZCSA.6409.SASS | 9 | 600 | 450 | 500 | 620*470*520 | ||||
ZCSA.6609.SASS | 600 | 620*620*520 | |||||||
ZCSA.6412.SASS | 12 | 600 | 450 | 635 | 620*470*650 | ||||
ZCSA.6612.SASS | 600 | 620*620*650 | |||||||
ZCSA.6415.SASS | 15 | 600 | 450 | 770 | 620*470*790 | ||||
ZCSA.6615.SASS | 600 | 620*620*790 | |||||||
ZCSA.6418.SASS | 18 | 600 | 450 | 900 | 620*470*920 | ||||
ZCSA.6618.SASS | 600 | 620*620*920 | |||||||
ZCSA.6422.SASS | 22 | 600 | 450 | 1080 | 620*470*1100 | ||||
ZCSA.6622.SASS | 600 | 620*620*1100 |
