Low Loss Cable
hellosignal
7101023
Coaxial Cable
75 ohm
UL, ETL, CE,CPR, RoHS
100m, 305m,500m,1000m,500ft,1000ft
roll, wooden spool, carton, pallet
10KM
Normally 25 working days
NINGBO, SHANGHAI
T/T, L/C at sight, D/P at sight
LLC 600 -75 ohm NO.7101023 Construction Parameters: | ||||||||
Inner Conductor | 2.74±0.02mm Copper Clad Aluminium Wire | |||||||
Dielectric | 11.56±0.15mm Foamed PE | |||||||
Shield | BAPA- Bonded Aluminum polyester Aluminum tape | |||||||
Outer Conductor | Tinned Copper Braid 90% Coverage | |||||||
Jacket | 14.99±0.2mm PE Black | |||||||
Electrical Characteristics: | ||||||||
Capacitance | 52.16 pF/m |
| ||||||
Impedance | 75±2 Ω | |||||||
Velocity of Propagation | 87% | |||||||
DC Breakdown Voltage | 4000 | |||||||
Jacket Spark(V.RMS) | 8000 | |||||||
Return loss | ||||||||
30MHz-3000MHz | ≥20.8 dB | |||||||
Mechanical and Envrionmental Properties: | ||||||||
Cable Bend Radius | Installation: 38.1mm | |||||||
Weight | 170 kg/km | |||||||
Maximum tension | 159 kg | |||||||
Recommended | Storage: | - 70 ℃ to +85℃ | ||||||
Installation: | - 40 ℃ to +85℃ | |||||||
Operating: | - 40 ℃ to +85℃ | |||||||
Cross Section: | ||||||||
 | ||||||||
Attenuation(20℃): | ||||||||
Frequency (MHZ) | Typical Attenuation(dB/100m) | Max Attenuation(dB/100m) | ||||||
30 | 1.32 | 1.45 | ||||||
50 | 1.64 | 1.81 | ||||||
150 | 2.95 | 3.25 | ||||||
220 | 3.60 | 3.97 | ||||||
450 | 5.24 | 5.78 | ||||||
900 | 7.54 | 8.29 | ||||||
1500 | 10.16 | 11.19 | ||||||
1800 | 11.48 | 12.60 | ||||||
2000 | 12.14 | 13.35 | ||||||
2500 | 13.78 | 15.15 | ||||||
3000 | 15.09 | 16.59 | ||||||
Order Informations: | ||||||||
Marking | HELLOSIGNAL LLC 600 75 Ohm COAXIAL CABLE ×××M | |||||||
Package | 500M/Wooden Drum | |||||||
Delivery time | Normally 25 days after received the deposit. | |||||||
Brand | HELLOSIGNAL® OR OEM | |||||||
Whatsapp/WeChat | 0086 18268009191 | |||||||
