■ Zion Communication: Fiber Drop Cable Manufacturer for Indoor & Outdoor FTTH

As the producer of FTTH drop cables, Zion Communication is recognized for providing reliable cables meant for FTTH (Fiber to the Home) systems. We boast over two decades of manufacturing and R&D efficiency, which enables us to serve the whole spectrum of high-performance, easy-installation fiber cables for indoor and outdoor use.

From fire-safe round cables to aerial self-supporting drop cables, Zion Communication will provide best running and cost-effective FTTH cabling solutions.

■ FTTH Fiber Drop Cable Application Scenarios

Indoor:

• A modern multi-family high-rise residential building combined with office gross area

• Structures telecommunication cable installation (LSZH requirement)

• Refurbishment of hidden piping and electric wiring

Outdoor:

• Rural FTTH installations in the air

• Utility poles, finished cable runs on cables

• Network of underground ducts.

• Got Questions? We’ve Got Answers.

■ Zion Communication Full Range of FTTH Drop Cable Products

Indoor Round Drop Cables (Flexible & Fire-Safe)

Models: GJYFJHH, GJYFJH, GYFJU

• The installation of fire-safe indoor FTTH cables calls for space-saving, cable-style design.

• LSZH Sheath → Abates the harsh fire emanation for increasing safety of the environment. Flexible & Varying Diameters → However, an additional advantage to the use of such cables in a tight indoor space is that routing them through walls, floors, and conduits becomes much easier.

PIC	Specification	Structure	Strength Member	Sheath	Diameter (mm)	Application	Key Advantage	Tensile Strength (N)
	GJYFJHH	Round, Tight-Buffered	Aramid Yarns	LSZH	4.8	Indoor FTTH	Fire-safe, larger diameter	250 (long-term) 800 (short-term)
	GJYFJH	Round, Tight-Buffered	Aramid Yarns	LSZH	3	Indoor FTTH	Compact, lightweight	60 (long-term) 120 (short-term)
	GYFJU	Round, Tight-Buffered	Aramid Yarns	LSZH	2.0–4.0 (typical)	Indoor /Outdoor FTTH	Flexible, versatile use	400–800 (varies by spec)

• Best For: Vertical structures, complexes, or closely situated inner areas of a building where hiding cables is preferred for consistency with the building's appearance and design regulations.

Flat Drop Cables (Slim, Durable & Easy to Install)

Models: GJXFH, GJXH, GJXH Small, GJXFDH/GJXDH, FDC

• Cables used in FTTH networks must be lightweight for convenience, yet robust enough to endure various environmental conditions during both indoor and outdoor applications.

• Lightweight Non-metallic BRP Frabicated FRP for Internal Use

• Metallic Steel Members for Sturdiness and Reliability under Extreme Conditions

• Increased Fiber Count Contained in Small Mountable Ducts Suitable for Fast High Capacity Links (with illustrational labels)

• Negligible Profile for Viability under Carpets, Walls, or Ducts in Construction Sites whatever, Indoor/Outdoor purposes.

PIC	Feature	Structure	Strength Member	Sheath	Dimensions (mm)	Fiber Count	Application	Key Advantage	Tensile Strength (N)
	GJXFH	Flat, Tight-Buffered	FRP	LSZH	2.0 × 3.0	1–4	Indoor / Outdoor FTTH	Lightweight, flexible	100 (long-term) / 200 (short-term)
	GJXH	Flat, Tight-Buffered	Steel Wire	LSZH	2.0 × 3.0	1–4	Indoor / Outdoor FTTH	Durable, strong	100 (long-term) / 200 (short-term)
	GJXH Small	Flat, Tight-Buffered	Steel Wire	LSZH	1.6 × 2.0	1–2	Indoor FTTH	Compact, small size	100 (long-term) / 200 (short-term)
	GJXFDH / GJXDH	Flat, Ribbon Fibers	FRP or Steel ire	LSZH	2.0 × 4.0	2–4 (Ribbon)	Indoor FTTH	High fiber count (ribbon)	40–200 (varies by spec)
	FDC	Flat, Central Tube	Steel Wire	LSZH	3.0 × 6.0	1–12	Indoor / Outdoor FTTH	Robust, higher capacity	300 (long-term) / 600 (short-term)

 Best For: Used for residential places, offices, or commercial installations for flexible routing with overlaying or underlaying minimum structures.

Self-Supporting Drop Cables (Aerial Ready)

Models: GJYXCH, GJYXFCH, GJYXFDCH/GJYXDCH, ASU, GYXY-8S, GYFXBY

• FTTH networks, which are established for aerial deployments, are required to have cables that persist heavy-duty use, do not corrode, and can cover a wide span without “sagging.”

• Steel or FRP Messenger: Used Fulfillment of High Flyers to have Requested Strength.

• PIC	Specification	Structure	Strength Member	Sheath	Dimensions (mm)	Fiber Count	Self-Supporting	Application	Key Advantage	Tensile Strength (N)
  	GJYXCH	Flat, Tight-Buffered	Steel Wire (Messenger + Core)	LSZH	2.0 × 5.1	1–4	Yes (Steel Wire Messenger)	Aerial FTTH	Durable, steel support	300 (long-term) / 600 (short-term)
  	GJYXFCH	Flat, Tight-Buffered	FRP (Messenger + Core)	LSZH	2.0 × 3.0	1–4	Yes (FRP Messenger)	Aerial FTTH	Lightweight, non-metallic	100 (long-term) / 200 (short-term)
  	GJYXFDCH / GJYXDCH	Flat, Ribbon Fibers	Steel Wire / FRP (Messenger + Core)	LSZH	2.0 × 6.2	2–4 (Ribbon)	Yes (Steel Wire Messenger)	Aerial FTTH	High fiber count, self-support	300 (long-term) / 600 (short-term)
  	ASU	Round, Uni-tube	FRP	HDPE	6.8/7.8	1–12	Yes (FRP)	Aerial FTTH (Long-span)	Long-span, robust	300 (long-term) / 600 (short-term)
  	GYXY-8S	Figure-8, Uni-tube	Steel Wire (Messenger) + Aramid	HDPE	2.8 x 4.6 x 8.8	1–12	Yes (Steel Wire Messenger)	Aerial FTTH	Figure-8 durability	500 (long-term) / 1250 (short-term)
  	GYFXBY	Flat, Uni-tube	FRP	PE	4.6 x 8.1	1–12	Yes (FRP)	Aerial FTTH	Flat, wind-resistant	400 (long-term) / 1400 (short-term)

 Best For: Greatly suitable for aerial FTTH deployments that are on a longer span and need endurance and reliability.

Outdoor Durable Drop Cables (Duct/Aerial Use)

Model: GYGXY

• In comparison to those in indoor environments, outdoor cables are exposed to UV light, moisture, and rodents, making them vulnerable to harsh climate effects.

• Non-metallic Glass Yarn Reinforcement: Contributes to lightweight with anti-corrosion qualifications, which can last a long time.

• HDPE Sheath: UV-resistant, moisture-proof, and rodent-resistant guarantee plus durability.

PIC	Specification	Structure	Strength Member	Sheath	Dimensions (mm)	Fiber Count	Self-Supporting	Application	Key Advantage	Tensile Strength (N)
	GYGXY	Uni-tube	Glass Yarn Tapes	HDPE	Varies (typically 5.0-8.0 mm, depending on fiber count)	1–4	No	Aerial, Duct (FTTH Drop Cable)	Lightweight, non-metallic, durable for outdoor use	600 (long-term) / 1500 (short-term)

 Best For: The cables for outdoor FTTH installation in aerial or duct settings that are required for long-term use.

■ Got Questions? We’ve Got Answers

What is the location of your organization?

The site is in the east of Hangzhou, Zhejiang, China, around 60 minutes away from Hangzhou Airport, along with the providing pickup service for visitors.

⏱ Will you be able to expedite the delivery considerably soon?

• Standard orders: 14 working days

• OEM/Custom: 30 workdays or less

Which form of payment do you accept?

• New clients: 30% deposit, 70% balance by T/T, L/C, D/P

• Long-term clients: L/C 30 days to 90 days, O/A available

Do you carry OEM/ODM offering?

We are happy to provide you tailored services.

• The custom of the sheath and colors

• The imprint and the logo

• Making-up of fiber count and structure.

What's the MOQ?

Minimum: 10 kilometers here are available. Directing OEM-seize may take place even at small runs.

✅ Do you have a quality control?

• Strict ISO 9001 quality system

• Selection of a raw material with premium quality

• Full-process testing: tensile, insulation, loss, durability

• Pre-inspection and the involvement of third-party quality assurance

• Warranty and after-sale service

What is packaging options we can get?

A special coiling, wooden drum- or reel-based packaging possibility

Branding a packaging and a labeling

Palletized safety for sea shipment.

Let’s discuss the shipping part of the process now. How is shipping handled?

We are ready to assist under both:

By means of your freight forwarder or dedicated logistics partners for the shipment management.

What’s your customer service after the purchase?

If a defect is found:

• Send photos + vein check

• Internal check and comparative analysis

• Confirm and compensate if verified

• A requisite loss should be prevented on future orders

■ FTTH Drop Cable Buyer’s Guide

Before you buy, consider:

Sheath Type → LSZH (indoor), HDPE (outdoor)

Strength Member → FRP (light), Steel (strong), Aramid (flexible)

Structure → Flat (hidden), Round (easy routing), Figure-8 (aerial)

Tensile Requirements → Choose based on span

Environment → UV, rodent, or flame risk

■ Why Choose Zion Communication as Your Drop Cable Supplier?

• Over 20 years of fiber drop cable manufacturer activity.

• OEM support and ODM support with R&D team.

• Flexible MOQ & fast production.

• This product is ISO, RoHS, CE certified.

• Exported to 80+ nations.

• Pip you will have unpredictable online assistance within 24 hours.

■ Certified Quality You Can Trust

• ISO 9001:2015 Certified Quality Management System

• RoHS & CE Compliant for Environmental and Safety Assurance

• CPR/EN50575 Certification for EU Construction Use

• China Telecom Supplier Qualification

• Test Reports from SGS / TÜV / Intertek (on request)

■ Customer Testimonials & Partners

What Our Clients Say

"Unreliable, fragile and accompanied with high installation lead time. Virtually every project in Europe that specifies FTTH in apartments has been serviced by them."

— Alex D., Network Integrator, Germany

"It is really cool that they have custom printing. You are lucky if you find a supplier with such short delivery time and available services."

— Mohammed A., FTTH Installer, Saudi Arabia

Trusted By:

• National Telecom Operators

• Education Networks in Africa

• Smart Manufacturing Plants

• Real Estate Developers

■ Production Capacity & Factory Strength

• Modern Fiber Cable Manufacturing Facility

• 10,000 factory area in meters square

• 3 laboratories doing tests in-house

• 12 advanced cable extrusion lines

• Daily output: 50,000 meters of FTTH drop cables

• Skilled R&D and OEM design team

■ Global Presence & Export Performance

We Serve Customers Worldwide

• Exported to 80+ Countries

• USA, Germany, Brazil, Saudi Arabia, Nigeria, India, Russia, Mexico, South Africa, Thailand

• Close to Hangzhou Airport — we support factory visits

• Flexible incoterms: FOB, CIF, DDP, EXW available

■ After-Sales & QA Promise

Your Quality is Our Priority

• Each batch is fully tested (tensile, attenuation, jacket, flame)

• Photo record before shipment

• Customized packing with tracking info

• After-sales support within 24 hours

• Warranty-backed cables: 10+ years lifespan

• Feedback loop to prevent repeat issues

■ Our Expert Team Cares

Work With People Who Care

• Our multilingual sales and technical team have helped thousands of companies deploy safe, high-speed FTTH networks.

• 7/24 Customer Support

• 20+ Years Industry Experience

• English, Spanish, Arabic, Russian support

• Free cable structure suggestions based on project specs

■ Get a Quote Today

Are you in search of a top-class fiber drop cable manufacturer?

Opt for Zion Communication - your dependable China FTTH cable manufacturer.

Our sales team can be contacted now or you can request a free sample.
