NO.7102033 RG59/U 2C 1.0 Figure 8

Construction Parameters:

Inner Conductor

0.032"/0.81mm/20AWG Bare Copper

Dielectric

0.144"/3.66±0.05mm Foamed Polyethylene

Shield

0.12mm ALMG-Braid(95%)

Jacket

0.236"/6.00±0.1mm  PVC/PE/LSZH

Power Wire Conductor

2x(34*0.2mmCCA )

Power wire Diameter of insulation

0.075"/1.9mmHDPE (Red,Black)

Jacket

5.05mm PVC/PE/LSZH

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor                         Resistance

The Max. at 20℃ shall be

<  33.5 Ohms/KM

Capacitance

67±2 pF/m

Impedance

75 ± 3 Ω

Return loss

between 5 and 1000MHz: > 22dB

Velocity of Propagation

0.66

Sparker Test (VAC)

3

Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20 ℃ to 60℃

Cable diamensions

6.0×5.05mm

Cross Section

Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100ft)

Max Attenuation (dB/100m)

5

0.86

2.82

55

2.05

6.73

83

2.45

8.04

187

3.60

11.81

211

3.80

12.47

250

4.10

13.45

300

4.45

14.60

350

4.80

15.75

400

5.10

16.73

450

5.40

17.72

500

5.70

18.70

550

5.95

19.52

600

6.20

20.34

750

6.97

22.87

865

7.52

24.67

1000

8.12

26.64

Order Informations:

Marking

HELLOSIGNAL RG59U +2C1.0 Figure 8
CCTV COAXIAL CABLE 7102033 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL^® OR OEM
