CC-Link
hellosignal
859148-859149
CC-Link
| ◆Application | |||||||||||
| Used to test sensor and propeller,with this cable, CC-Link system can handle control data and information data quickly. Apply to Automobile industry,Hotel monitor systems. | ◆Technical data | ||||||||||
| ● Temperature range | |||||||||||
| .-40℃ to 80℃ | |||||||||||
| ◆Cable Construction | ● Characteristic impedance | ||||||||||
| Conductor: Stranded bare copper wire | 110±15 Ohm | ||||||||||
| Insulation: Foam PE | 110±6 Ohm（5MHz） | ||||||||||
| Drain wire: Tinned copper wire | ● Min bending radius | ||||||||||
| Shield: AL/Mylar screen and TC braid | 15x cable diameter | ||||||||||
| Jacket: see attached list | ● Loop conductor DC resistance at 20℃ | ||||||||||
| Color: Red | ≤76 ohm/km | ||||||||||
| ◆Product Feature | ● Test voltage | ||||||||||
| Oil and grease resistance | 1500V 1min,no breakdown | ||||||||||
| AL/Mylar and copper wire braid,excellent Anti-EMI performance | |||||||||||
| Abrasion resistance,Anti-hydrolysis | |||||||||||
| Product List | |||||||||||
| Item NO. | Spec. | Jacket | Nominal OD(mm) | Copper.weight approx (kg/km) | Weight approx (kg/km) | ||||||
| 859148 | 3*1*20AWG | PVC | 7.7 | 34 | 83 | ||||||
| 859149 | 3*1*20AWG | PUR | 7.7 | 34 | 80 | ||||||
| Order Informations: | |||||||||||
| Marking | HELLOSIGNAL CC-Link Cable | ||||||||||
| Package | 500FT/PULL BOX, 1000FT/Wooden Spool,Pallet | ||||||||||
| Delivery time | Normally 20-25 days after received the deposit. | ||||||||||
| More informations | please contact with us. | ||||||||||
| Brand | HELLOSIGNALTM OR OEM | ||||||||||
