HELLOSIGNAL 590 P / 590 CP

  • HELLOSIGNAL 590 P / 590 CP

  • hellosignal

  • 7141800

Availability:

Product Description

HELLOSIGNAL 590 P / 590 CP

HELLOSIGNAL 590 P 590 CP

HELLOSIGNAL 590 P 590 CP..

Application

HELLOSIGNAL® 590 P is a color-coded, flexible power and control cable with a rugged,
highly abrasion-resistant yellow polyurethane jacket. It is UV-resistant and performs
very well in cold-temperature indoor and outdoor applications.
HELLOSIGNAL® 590 CP is the shielded version, with an overall foil tape,
drain wire, and tinned copper braid for EMI and RFI protection.

Recommended Applications

Portable hand tools; utility & forestry trucks & equipment; cold temperature applications;
areas where the cable can be cut or damaged by sharp objects

Unshielded Construction

Conductors:  Finely stranded tinned copper

Insulation: TPE

Jacket: Polyurethane; yellow

Shielded Construction

Conductors:  Finely stranded tinned copper

Insulation: TPE

Shielding: Overall foil tape with drain wire; tinned copper braid (85% coverage)

Jacket: Polyurethane; yellow

Application Advantage

• Rugged PUR jacket resists cuts, nicks & abrasions
• TPE insulation for superior cold-temperature flexibility
• Safety colored yellow jacket
• Good for damp environments
• UL & CSA AWM approval

Technical data

 Minimum Bend Radius

for installation :  5 x cable diameter

for shielded    :  8 x cable diameter

 Temperature Range

for flexible use : -50°C to +80°C

Technical data

 Nominal Voltage

600V

Test Voltage

2000V

Conductor Stranding

Class 5 fine wire*

*  18 AWG meets only the Class 5 cross section and DC resistance

Technical data

 Color Code

Color-coded per Chart 1, page 672 (#4 conductor is green/yellow)

 Approvals

UL:




AWM 20234
UL Oil Res I/II

Attributes:

UL Oil Res I/II

Sunlight Resistant

NFPA 79

Canada:

CSA AWM I/II A/B FT1

Additional:

CE & RoHS

590 P Product List

Item No.

Number of
Conductors

Nominal Outer(in)

Copper.weight (lbs/mft)

Approx.weight (lbs/mft)

18 AWG (1.00 mm²)

7141800

2

0.293

13

44

7141801

3

0.308

19

51

7141802

4

0.332

25

64

7141803

5

0.357

31

77

7141804

7

0.390

44

95

16 AWG (1.50 mm²)

7141810

2

0.315

18

51

7141811

3

0.331

26

64

7141812

4

0.357

39

77

7141813

5

0.387

44

90

7141814

7

0.418

62

115

14 AWG (2.50 mm²)

7141820

3

0.360

43

82

7141821

4

0.389

57

101

7141822

5

0.422

72

123

12 AWG (4.00 mm²)

7141825

3

0.399

72

117

7141826

4

0.447

96

145

12 AWG (4.00 mm²)

7141830

3

0.485

105

161

7141831

4

0.532

139

205

590 CP Product List

Item No.

Number of
Conductors

Nominal Outer(in)

Copper.weight (lbs/mft)

Approx.weight (lbs/mft)

18 AWG (1.00 mm²)

7141840

3

0.330

34

73

7141841

4

0.354

41

84

7141842

5

0.379

50

99

16 AWG (1.50 mm²)

7141845

2

0.346

37

73

7141846

3

0.362

46

86

7141847

4

0.388

56

99

7141848

5

0.418

67

117

* 2c cable does not include ground

14 AWG (2.50 mm²)

7141850

3

0.391

71

108

7141851

4

0.420

88

130

7141852

5

0.458

103

161

12AWG (4.00 mm²)

7141860

3

0.442

109

156

7141861

4

0.479

136

190

7141862

5

0.518

160

231

10AWG (6.00 mm²)

7141865

3

0.521

147

216

7141866

4

0.564

184

262

7141867

5

0.635

222

315

Order Informations

Marking

HELLOSIGNAL 590 P/590 CP XXXFT/M

Package

100M/Reel, 300M/Wooden Spool

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
