Automotive Cable
hellosignal
Japanese Standard
Normally 25 working days
NINGBO, SHANGHAI
FLR11Y Automotive Cable | ||||||||||
Product Description: | ||||||||||
Conductor | Cu-ETP1 bare according to DIN EN 13602 | |||||||||
Insulation | PVC Outer | |||||||||
Sheath | TPE-U | |||||||||
Standard Compliance | ISO 6722 Class B | |||||||||
Special properties | Flame retardant, Highly resistant against acids,lyes,petrol and diesel | |||||||||
Technical Parameters | Operating temperature:–40 °C to +105 °C | |||||||||
Application: | ||||||||||
This PVC insulated low-tension automotive cable is used in motorcycles and other motor vehicles for starting, charging,lighting,signal and instrument panel circuits. | ||||||||||
 | ||||||||||
Zion's Hot Types of FLR11Y Automotive cable | ||||||||||
Conductor | Insulation | Cable | ||||||||
Nominal | No. and Dia. of Wires | Diameter of Conductor max. | Electrical resistance at 20℃ Max. | Nominal thickness | Diameter of Core | Sheath wall thickness | Overall Diameter Min. | Overall | Weight | |
mm2 | No./mm | mm | mΩ/m | mm | mm | mm | mm | mm | Kg/km | |
2x0.75 | 42/0.16 | 1.20 | 24.70 | 0.40 | 1.90 | 0.80 | 5.20 | 5.60 | 47.00 | |
3x1 | 32/0.21 | 1.50 | 18.50 | 0.35 | 2.00 | 0.70 | 5.60 | 6.00 | 54.00 | |
3x1.5 | 30/0.26 | 1.70 | 13.30 | 0.40 | 2.40 | 0.75 | 6.50 | 6.90 | 71.00 | |
Note: Other configurations, sizes, colors and length not specified herein are available upon request. | ||||||||||
